KYN28-24 HV 29KV Power Box
KYN28-24 Type armored removable ac metal enclosed switchgear (hereinafter referred to as switchgear) It is suitable for three-phase ac 50Hz power system to receive and distribute electric energy, control, protect and monitor the circuit
Dekri teren
KYN28-24 HV 29KV Power box
Summary:
KYN28 -24 Type switch cabinet is three phase AC50Hz,rated voltage 24KV indoor power distribution equipment .As power plants ,substations ,industrial &mining enterprises to accept amd distribute of electric energy to control ,protect and monitor ,circuit ,ect.Can also be used to control the place of frequent operation .
Structure Description:
Switchgear are requested designed according to GB3906 and Ie 298.The whole switchgear can be extracted from the cabinet and spare parts (trolley) two components ,Cabinet structure are made of aluminum deposited zine plate or galvanized plate bolted combination forming a metal partition separationg the part of the circut break room,main busbar room cable room and relay control room.and all metal construction were grounded ,each com-partment of the main circuit system has separste pressure release channel,In the cable compartment can be set to 40*6mm ground busbar .
Main characteristics:
- simple and effective ‘Five Anti’lockout to prevent misuse
- Can be equipped with VS1.VD4,3AH vacuum contactors ,etc
- Can be equipped with voltage transformer hancart,isolation handcart,fuses ,ect,Used ,Used same use interchangeable .
- The switch cabinet can be wall mounted ,front cabinet maintenance ,reduce floor space .
- The circuit breaker compartment and cable compartment heater can be installed separately ,to prevent condenstation and corrosion ;
- Cable ample room space,can be connected to a plurality of cables .
- Shell protection grade IP4*,among compartment protection class IP2*:
- The meterial can be gavanized sheet can be deposited aluminum and zinc plate production .
Cabinet outline dimensions(mm)(not including door)
| Height | Width | Depth |
| 2300 | 800 | 1800 |
| 2300 | 1000 | 1800 |
Advantages:
good compatibility, stable and reliable performance, free maintenance and long service life, is old-fashioned contactor is the ideal substitute of products
b) Humidity:Monthly average humidity 95%; Daily average humidity 90% .
c) Altitude above sea level:Maximum installation altitude: 2500m
d) Ambient air not apparently polluted by corrosive and flammable gas, vapor etc.
e) No frequent violent shake
FACTORY
CERTIFICATE
EXHIBITION
COMPANY OVERVIEW
FAQ
Q5 : Is OEM/ODM available?
A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.
Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.
Q7 : Can the price be negotiated?
A: Yes, the price is negotiable. It can be changed according to your quantity or package
Q8 : How about inspection?
A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.
Q9 : What is payment terms?
A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
